87m / DP 2 / 230ts BP AHTS Vessel / #1068072

VESSEL INFO

• Offer type Ship for charter

• Type Anchor Handling Tug Supply Vessel (AHTS)

• Year of construction 2009

• Length 87.4m

• Width 21m



• Deadweight 3912 metric tons

• Capacity 5 ML



• PRICE Price on request


DESCRIPTION

GRS identification number: #1068072

LOA 87.4 m
Beam 21 m
Draft 7.77 m
Bollard Pull : 230 tons
Dynamic Positioning of class : DP 2
Free Deck area about 755m² with a deck strength of 12 metric tonnes per square meter
Capable of supplies of 998m³ Fuel Oils, 898m³ FW, 861m³ Liquid Mud and 861m³ Brine
1 Crane / Gear installed with a max lifting capacity of 5 tons
1 Crane / Gear installed with a max lifting capacity of 3 tons
AF installed
Built in year 2009
Design is : UT 731-CD
Class : DNV
Flag : Brazil
Gross Tonnage of 6,107 and Nett Tonnage of 1,832
Deadweight : 3,912 metric tonnes
Ice classed 1C
Total 40 berths
Speed : 12 knots
Engines : 6 x Bergens / Rolls-Royce Marine AS B32:40L9P, 17,400 kw, 750 rpm, Propellers 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
Auxiliaries Engines : 4 Caterpillar 2,130 kw, Bowthruster + Sternthruster (1 Bow Thwart. FP thruster 1,500kw + 1 Bow Retract. dir. thruster 1,800kw + 2 Stern Thwart. FP thruster 1,200kw)
