95m / DP 2 / 344ts BP AHTS Vessel / #1069206

VESSEL INFO

• Offer type Ship for charter

• Type Anchor Handling Tug Supply Vessel (AHTS)

• Year of construction 2010

• Length 95m

• Width 24m



• Deadweight 5000 metric tons

• Capacity 250 ML



• PRICE Price on request


DESCRIPTION

GRS identification number: #1069206

LOA 95 m
Beam 24 m
Draft 7.81 m
Bollard Pull : 344 tons
Dynamic Positioning of class : DP 2
Free Deck area about 760m² with a deck strength of 10 metric tonnes per square meter
Capable of supplies of 2,006m³ Fuel Oils and 932m³ FW
Heli Deck installed
1 Crane / Gear installed with a max lifting capacity of 12 tons
1 Crane / Gear installed with a max lifting capacity of 5 tons
1 Crane / Gear installed with a max lifting capacity of 3 tons
1 AF installed with a max lifting capacity of 250 tons
Built in year 2010
Design is : Aker AH 12
Class : DNV
Flag : Norway
Gross Tonnage of 8,053 and Nett Tonnage of 2,415
Deadweight : 5,000 metric tonnes
Total passenger capacity 70
Speed : 12 knots
Engines : 2 x Wartsila / Wartsila Finland Oy 16V32, 15,360 kw, 750 rpm, Propellers 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
Auxiliaries Engines : 4 Caterpillar 2,200 kw, Bowthruster + Sternthruster (2 Bow Thwart. FP thruster 1,200kw + 1 Bow Retract. dir. thruster 1,500kw + 1 Stern Retract. dir. thruster 1,500kw + 1 Stern Thwart. FP thruster 1,200kw)
