94m / DP 2 / 277ts BP AHTS Vessel / #1068374

VESSEL INFO

• Offer type Ship for charter

• Type Anchor Handling Tug Supply Vessel (AHTS)

• Year of construction 2009

• Length 93.8m

• Width 23m



• Deadweight 4925 metric tons

• Capacity 250 ML



• PRICE Price on request


DESCRIPTION

GRS identification number: #1068374

LOA 93.8 m
Beam 23 m
Draft 8 m
Bollard Pull : 277 tons
Dynamic Positioning of class : DP 2
Free Deck area about 721m² with a deck strength of 10 metric tonnes per square meter
Capable of supplies of 1,880m³ Fuel Oils, 706m³ FW, 639m³ Liquid Mud and 964m³ Brine
Fire Fighting System installed
1 Crane / Gear installed with a max lifting capacity of 250 tons
2 Cranes / Gears installed with a max lifting capacity of 5 tons
1 KNB installed with a max lifting capacity of 25 tons
None installed with a max lifting capacity of 12 tons
Built in year 2009
Design is : Ulstein A122
Class : DNV
Flag : Norway
Gross Tonnage of 6,839 and Nett Tonnage of 2,051
Deadweight : 4,925 metric tonnes
Ice classed 1C
Total passenger capacity 68 with 68 berths
5 cabins with 1 berth
15 cabins with 1 berth
24 cabins with 2 berths
Speed : 15 knots
Engines : 2 x Wartsila / Wartsila Finland Oy 9L32, 9,000 kw, 750 rpm, Propellers 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
Auxiliaries Engines : Bowthruster + Sternthruster (2 Bow Thwart. FP thruster 1,200kw + 1 Bow Retract. dir. thruster 1,400kw + 2 Stern Tunnel thruster 1,050kw)
