81m / DP 1 / 206ts BP AHTS Vessel / #1063041

VESSEL INFO

• Offer type Ship for charter

• Type Anchor Handling Tug Supply Vessel (AHTS)

• Year of construction 2005

• Length 80.5m

• Width 18m



• Deadweight 3678 metric tons

• Capacity 10 ML



• PRICE Price on request


DESCRIPTION

GRS identification number: #1063041

LOA 80.5 m
Beam 18 m
Draft 6.6 m
Bollard Pull : 206 tons
Dynamic Positioning of class : DP 1
Free Deck area about 390m² with a deck strength of 10 metric tonnes per square meter
Capable of supplies of 1,056m³ Fuel Oils, 942m³ FW and 872m³ Brine
Fire Fighting System of type FiFi 2 installed
1 Crane / Gear installed with a max lifting capacity of 10 tons
1 Crane / Gear installed with a max lifting capacity of 2 tons
Built in year 2005
Design is : UT 722-L
Class : DNV
Flag : Brazil
Gross Tonnage of 3,678 and Nett Tonnage of 1,104
Deadweight : 3,678 metric tonnes
Total 30 berths
Speed : 13.5 knots
Engines : 4 x Bergens / Rolls-Royce Marine AS BRM-8, 12,370 kw, 750 rpm, Propellers 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
Auxiliaries Engines : 2 Cummins 504 kw, Bowthruster + Sternthruster (1 Bow Tunnel thruster 883kw + 1 Bow Retract. dir. thruster 1,120kw + 1 Stern Tunnel thruster 883kw)
