91m / DP 2 / 285ts BP AHTS Vessel / #1072428

VESSEL INFO

• Offer type Ship for charter

• Type Anchor Handling Tug Supply Vessel (AHTS)

• Year of construction 2014

• Length 91m

• Width 22m



• Deadweight 4600 metric tons

• Capacity 60 ML



• PRICE Price on request


DESCRIPTION

GRS identification number: #1072428

LOA 91 m
Beam 22 m
Draft 8.2 m
Bollard Pull : 285 tons
Dynamic Positioning of class : DP 2
Free Deck area about 828m² with a deck strength of 10 metric tonnes per square meter
Capable of supplies of 1,156m³ Fuel Oils, 1,004m³ FW and 650m³ Liquid Mud
Fire Fighting System of type FiFi 2 installed
1 Crane / Gear installed with a max lifting capacity of 60 tons
1 Crane / Gear installed with a max lifting capacity of 42 tons
2 Cranes / Gears installed with a max lifting capacity of 12 tons
1 Crane / Gear installed with a max lifting capacity of 11 tons
Built in year 2014
Design is : VS 491-CD
Class : DNV
Flag : Norway
Gross Tonnage of 7,347 and Nett Tonnage of 2,200
Deadweight : 4,600 metric tonnes
Ice classed 1C
Speed : 12 knots
Engines : 2 x Wartsila / Wartsila Finland Oy 16V32, 16,000 kw, 750 rpm, Propellers 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
Auxiliaries Engines : 2 Caterpillar 1,492 kw, Bowthruster + Sternthruster (2 Bow Tunnel thruster 1,000kw + 1 Bow Retract. dir. thruster 830kw + 2 Stern Tunnel thruster 1,000kw)
