59m / DP 1 / 66ts BP AHTS Vessel

VESSEL INFO

• Offer type Ship for charter

• Type Anchor Handling Tug Supply Vessel (AHTS)

• Year of construction 2009

• Length 59.25m

• Width 15m



• Deadweight 1400 metric tons

• Capacity 3 ML



• PRICE Price on request


DESCRIPTION

GRS identification number: #1072897

LOA 59,25 m
Beam 15 m
Draft 4,95 m
Bollard Pull : 66 tons
Dynamic Positioning of class : DP 1
Free Deck area about 350m²
Capable of supplies of 500m³ Fuel Oils, 372m³ FW and 187m³ Dry bulk
Fire Fighting System of type FiFi 1 installed
1 Crane / Gear installed with a max lifting capacity of 3 tons
Built in year 2009
Design is : DN59M
Class : Vietnam Register
Flag : Vietnam
Gross Tonnage of 1.678 and Nett Tonnage of 503
Deadweight : 1.400 metric tonnes
Total passenger capacity 42 with 42 berths
1 cabin with 4 berths
2 cabins with 3 berths
4 cabins with 8 berths
Speed : 10 knots
Engines : 2 x Caterpillar / Caterpillar Inc 3516B-HD, 3.787 kw, 1.600 rpm, Propellers 2 Controllable Pitch (Port Side)
Auxiliaries Engines : 3 Caterpillar 383 kw, Bowthruster + No Sternthruster (1 Bow Tunnel thruster 6 tonne Kawasaki KT-5583)
