75m / DP 2 / 202ts BP AHTS Vessel

VESSEL INFO

• Offer type Ship for charter

• Type Anchor Handling Tug Supply Vessel (AHTS)

• Year of construction 2008

• Length 74.5m

• Width 17.2m



• Deadweight 3000 metric tons

• Capacity 5 ML



• PRICE Price on request


DESCRIPTION

GRS identification number: #1067185

LOA 74,5 m
Beam 17,2 m
Draft 6,8 m
Bollard Pull : 202 tons

Dynamic Positioning of class : DP 2
Free Deck area about 520m² with a deck strength of 10 metric tonnes per square meter
Capable of supplies of 1.100m³ Fuel Oils, 725m³ FW, 540m³ Liquid Mud and 515m³ Brine
Fire Fighting System of type FiFi 1 installed
1 Crane / Gear installed with a max lifting capacity of 5 tons
1 Crane / Gear installed with a max lifting capacity of 3,5 tons

Built in year 2008
Design is : Havyard 842
Class : (Det Norske Veritas)
Flag : Norway
Gross Tonnage of 2.807 and Nett Tonnage of 857

Deadweight : 3.000 metric tonnes
Ice strength

Total 42 berths
6 cabins with 1 berth
8 cabins with 2 berths
2 cabins with 6 berths
2 cabins with 4 berths

Speed : 15 knots
Engines : 2 x MaK / Caterpillar Motoren 12VM32C, 12.000 kw, 750 rpm, Propellers 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
Auxiliaries Engines : 2 Caterpillar 600 kw, Bowthruster + Sternthruster (1 Bow Thwart. CP thruster 883kw + 1 Bow Retract. dir. thruster 883kw + 1 Stern Thwart. CP thruster 883kw)
