74m / DP 1 / 178ts BP AHTS Vessel

VESSEL INFO

• Offer type Ship for charter

• Type Anchor Handling Tug Supply Vessel (AHTS)

• Year of construction 1992

• Length 73.6m

• Width 16.35m



• Deadweight 2783 metric tons

• Capacity 5 ML



• PRICE Price on request


DESCRIPTION

GRS identification number: #1049862

178ton BP AHT in good condition, in class and immediately available for sale.

Built: 1992
M/E: 15612 BHP (four engines)
Props: 2 x CPP in kort nozzles
Bollard pull: 178tons
Dyn. Pos: DP 1
FiFi: FiFi 2
Misc: Oil Rec
Class: RMRS Class

Speed: max. 16knots / eco 10knots (burning MGO)

Deck: Cargo 610tons / 5tons/m² / 554m² clear deck area
Fuel: 1.050m³
FW: 860m³
Ballast: 662m³
Drill water: 775m³
Brine: 396m³
Rig chain locker: 2 x 80m³

Accommodation: Bunks 29 (12 x single cabins, 2 x 4bed cabins, 1 x 3bed cabin, 1 x 6bed cabin)

Anchor windlass: Brattvagg
Drum: 2 x 640mm
Gypsy: 2 x Gypsies 560mm
Smit bracket: 1 x 250tons
Bow anchors: 3 x 2000kg
capstans: 2 x 10tons
Tugger winch: Brattvagg 2 x 15tons
Tugger wire: 2 x 120m 18mm

For further details and inspection please get in touch with your dedictaed broker at Global Renewables Shipbrokers.
LOA 73,6 m
Beam 16,35 m
Draft 6,86 m
Bollard Pull : 178 tons

Dynamic Positioning of class : DP 1
Free Deck area about 554m² with a deck strength of 5 metric tonnes per square meter
Capable of supplies of 1.050m³ Fuel Oils, 710m³ FW, 462m³ Liquid Mud and 396m³ Brine
Fire Fighting System of type FiFi 2 installed
1 Crane / Gear installed with a max lifting capacity of 5 tons

Built in year 1992
Design is : ME-303 Mk II
Class : Russian Maritime Register
Flag : Russia
Gross Tonnage of 2.335 and Nett Tonnage of 924

Deadweight : 2.783 metric tonnes

Total passenger capacity 14 with 21 berths

Speed : 12 knots
Engines : 4 x Wartsila / Wartsila Diesel Oy 8R32E, 11.326 kw, 750 rpm, Propellers 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
Auxiliaries Engines : 2 Caterpillar, Bowthruster + Sternthruster (1 Bow Thwart. CP thruster 800kw + 1 Bow Retract. dir. thruster 800kw + 1 Stern Tunnel thruster 882kw)
