99m / DP 2 Offshore Support & Construction Vessel

VESSEL INFO

• Offer type Ship for charter

• Type Support Vessel

• Year of construction 2011

• Length 98.62m

• Width 18.99m



• Deadweight 4569 metric tons

• Capacity 150 ML



• PRICE Price on request


DESCRIPTION

GRS identification number: #1071481
- X-Bow design, anti-heeling, 13.9knots transit speed
- 150 t (AHC) offshore crane for handling of subsea equipment over the shipside or through the moonpool
- 935m² deck area with available sheltered area (160m²) / deck load 10t/m²
- Hangar with integrated LARS for deployment of Work Class ROVs on port & starboard sides
- Large moonpool (7,2 x 7,2 m) for installation of equipment onto the seabed. Interface (structural) for Module Handling Tower
- Accommodation for up to 75 Persons
General details as follows:
LOA 98,62 m
Beam 18,99 m
Draft 6,3 m
Built in year 2011
Design is : Ulstein SX130
Class : DNV
Flag : Marshall Islands
Gross Tonnage of 6.072 and Nett Tonnage of 1.822
Dynamic Positioning of class : DP 2
Free Deck area about 935m² with a deck strength of 10 metric tonnes per square meter
Heli Deck installed
Moon pool 7,2m x 7,2m installed
1 Crane / Gear installed with a max lifting capacity of 3 tons
1 KNB installed with a max lifting capacity of 150 tons
1 KNB installed with a max lifting capacity of 6 tons
Deadweight : 4.569 metric tonnes
Bollard Pull : 60 tons
Ice classed 1C
Capable of supplies of 1.650m³ Fuel Oils and 1.000m³ FW
Total passenger capacity 60 with 78 berths
10 cabins with 1 berth
10 cabins with 1 berth
12 cabins with 2 berths
17 cabins with 2 berths
Speed : 10,5 knots
Engines : 5 x Caterpillar / Caterpillar Inc 3516B, 9.505 kw, 1.800 rpm, Propellers 1 Azimuth Elec. Dr. (Port Side) + 1 Azimuth Elec. Dr. (Starboard)
Auxiliaries Engines : Bowthruster + No Sternthruster (2 Bow Tunnel thruster 1.200kw + 1 Bow Retract. dir. thruster 850kw)
