92m / 28m Pontoon / Barge / #1077351

VESSEL INFO

• Offer type Ship for sale

• Type Barge

• Year of construction 2012

• Length 92.38m

• Width 27.997m

• Deadweight 1500 metric tons

• Capacity 32.5 ML

• Asking price Price on request


DESCRIPTION

GRS identification number: #1077351

Type of vessel: Self Unloading Barge
Classification: IRS
Class notation (Hull): IW-,”Self Propelled and self Unloading Vessel & Deck Strengthened for cargo load 5t/m2 “,Zone1.IY.
Builder: Nantong Tongmao Ship Building Ltd.
Year Built: 2012, Date of Keel Laid – 08-03-2011
LOA: 92.375 m
LBP: 89.40 m
Breadth: 28.00 m
Depth Moulded: 6.50 m
Max Draft: 3.50m
Trial Speed: 6 knots
GRT: 5386 GT
NRT: 1616 NT
Freeboards (Type B freeboard): Fresh water – 2935 mm, Summer – 3012 mm, Length of parallel body – 88.5 Mtrs
Loadline assigned : 2368 mm aft of Fr.21
Main Engine Particulars (P,S&C): MAN-STX 6L23/30H 800KW@750 RPM X 3 sets
Aux Engine (1 no): CUMMINS QSM 11D(M) (Gen.Set. 265 KW@1500 RPM)
Thruster: HRP 4011 WM, L-DRIVE VERTICAL INPUT DRIVE, 500KW, 1200 RPM
Propeller: 1350 mm, fixed pitch, 4 bladed Ni-Al Bronze
Electric current: 3 Ph, 400 V, 50 Hz
Anchors: JIS Stockless 2850 Kg (P&S) Carbon Cast Steel Anchor
Anchor chains (P&S): 48mm 18 Length X 27.5 Mtrs = 495 Mtrs
Deck cranes: Hoisting capacity Grab- 30 Tons, Hoisting capacity general cargo- 32.5 Tons.
Provision crane: SWL- 1.5 Tons
LOA 92.38 m
Beam 28 m
Draft 3.51 m
Built in year 2012
Class : Indian Register of Shipping
Flag : India
Gross Tonnage of 5,386 and Nett Tonnage of 1,616
Deadweight : 1,500 metric tonnes
1 Crane / Gear installed with a max lifting capacity of 32.5 tons
1 Crane / Gear installed with a max lifting capacity of 1.5 tons
Speed : 6 knots
Engines : 3 x MAN / STX Engine Co Ltd 6L23/30H, 2,310 kw, 750 rpm, Propellers 1 Directional (Port Side) + 1 Directional (Starboard)
Auxiliaries Engines : 1 Cummins 200 kwThruster : 500kw HRP 4011 WM, L Drive Vertical input
