2026 85M 9300HP Electric Propulsion Multipurpose Anchor Handling Tug Supply (AHTS) Vessel

VESSEL INFO

• Offer type Ship for sale

• Type Anchor Handling Tug Supply Vessel (AHTS)

• Classification China Classification Society

• Year of construction 2026

• Length 85.5m

• Width 18.2m

• Depth 7.8m

• Deadweight 4000 metric tons

• Asking price $ 29 700 000


DESCRIPTION

2026 85M 9300HP Electric Propulsion Multipurpose Anchor Handling Tug Supply (AHTS) Vessel

Ship Type: Multipurpose Work Vessel
Classification Society: CCS (IACS)
Navigation Area: Unrestricted, A1+A2+A3
Vessel Status: Newbuild, under construction, delivery in October 2026
Core Positioning: Integrating offshore operations, supply, firefighting, oil recovery, and dynamic positioning; suitable for various offshore operations in coastal waters.

I. Principal Dimensions & Deadweight Capacity

· Length Overall: 85.5m
· Breadth Moulded: 18.2m
· Depth Moulded: 7.80m
· Scantling Draft: 6.5m
· Gross Tonnage: 3818t
· Deadweight: 4000t (at design draft of 6.5m)
· Deck Area: 800㎡
· Deck Strength: 5t/㎡
· Accommodation: 50 persons (16 crew + 34 special/industrial personnel)
· Berths: 50 (excluding 24 IP)
· Minimum Manning: 16 persons

II. Propulsion System & Speed

1. Main Propulsion (Main Engines): Cummins QSK-50, 1709KW × 4 (Total 9300HP)
Electric Propulsion Azimuth Thrusters 1800KW × 2
2. Dynamic Positioning: DP2, Bow Thruster 800KW × 2
3. Generator Sets: 4 × 1600KW Cummins CCFJ1600-Z-W-MTCM + 1 × 270KW Cummins Emergency Generator Set
4. Speed: Max 14.5 Knots, Economy 12.0 Knots; at 4.8m draft, speed approx. 14.2 Knots
5. Towing Capability: 80T Hydraulic Towing Winch, Bollard Pull 115T, 150T Towing Pin/Shark Jaw, 48CM AM3 Combined Windlass
6. Deck Equipment: 10T Cargo Handling Winch, 10T Mooring Capstan

III. Core Tank Capacities

· Drill Water: 1980m³
· Mud: 1000m³
· Fuel Oil: 1250m³ (including 946m³ for external fuel supply)
· Potable Water: 830m³
· Bulk Material: 300m³
· Oil Recovery: 850m³
· Supporting: Full range of tanks including ballast water, base oil, brine, recovered oil, etc.

IV. Class Notation & Certification

★CSA CSA Offshore Tug/Supply Ship; Stand-By Ship; SPS; Fire Fighting Ship 1; Oil Recovery Ship (Not applicable for products with flash point ≤60℃); PSPC (B); Ice Class B; In-Water Survey; Crew Accommodation (MLC)
★CSM AUT-0, DP-2, G-EP; G-ECO (BWM(T))

V. Safety / Fire Fighting / Anti-Pollution Equipment

Fire Fighting Equipment

· 1200m³/h Fire Monitors × 2
· Water Curtain System, Spraying System (both equipped)

Life-Saving Equipment

· CRVF-A20 (Ⅲ) Liferafts × 6, NM60R Rescue Boat × 1
· 136 Lifejackets, 60 Immersion Suits, 8 Lifebuoys

Anti-Pollution Function: Professional oil recovery configuration, meeting offshore anti-pollution operation requirements.

VI. Navigation / Communication Equipment (Full JRC Brand)

Radar, Inmarsat-C, NBDP, GPS, VHF, EPIRB, SART, NAVTEX, AIS, SSB, Gyrocompass, Magnetic Compass, Echo Sounder, Weather Fax, Log, EPIRB, VDR, Security Alarm System, Electronic Chart Display and Information System (ECDIS).

The EX Chinese port price is usd29.7 million
