【for sale】FOR SALE: 10,880 BHP AHTS with FIFI 1 & DP 2

VESSEL INFO

• Offer type Ship for sale

• Type Anchor Handling Tug Supply Vessel (AHTS)

• Classification China Classification Society

• Year of construction 2007

• Length 70m

• Width 16.8m

• Depth 7.5m

• Asking price Price on request


DESCRIPTION

【for sale】FOR SALE: 10,880 BHP AHTS with FIFI 1 & DP 2
1. GENERAL INFORMATION
Vessel Type: Anchor Handling Tug & Supply Vessel (AHTS)
Class: CCS
Class Notation: Tug / Offshore Supply Ship / Fire Fighting Ship 1; Anchor Handling; DP-2
Year Built: 2007
Builder: MMA, Singapore
Flag: China
Operation: Worldwide offshore towing, platform support, fire-fighting, safety standby, emergency evacuation, seismic services
2. PRINCIPAL PARTICULARS
Length Overall (LOA): 70.0 m
Length Between Perpendiculars (LBP): 64.0 m
Breadth Moulded: 16.8 m
Depth Moulded: 7.5 m
Max Draft: 6.1 m
Deadweight (DWT): 2,099 t
Gross Tonnage (GRT): 2,708
Net Tonnage (NRT): 812
3. PROPULSION & MANEUVERING
Main Engines: 2 × Wärtsilä 8L32
Total Power: 10,880 BHP (5,440 BHP each)
Propellers: 2 × CPP, Kamewa 50XF5/4T
Bow Thrusters: 2 × 680 kW, 10.5 t thrust
Stern Thruster: 1 × 680 kW, 10.5 t thrust
Bollard Pull: 125.0 t at 100% MCR
4. DYNAMIC POSITIONING SYSTEM
DP System: Kongsberg K-Pos DP 21
DP Class: DP 2
Joystick Control: Kongsberg cJoy
5. ELECTRICAL SYSTEM
Main Generators: 2 × CAT 3408C, 410kW, 440V, 60Hz, 3Ph
Shaft Generators: 2 × Leroy Somer LSA 53 S75-4P, 2300kW
Emergency Generator: 1 × CAT 3054T, 99kW, 440V, 60Hz, 3Ph
6. CARGO DECK & STORAGE
Main Deck Area: 450.0 m²
Deck Strength: 7.5 t/m²
Deck Cargo Capacity: 800 t
Tank Capacities:
Fuel Oil: 1,238 m³
Potable Water: 389 m³
Drill Water: 420 m³
Liquid Mud / Base Oil / Brine: 489 m³ (6 tanks)
Dry Bulk: 226 m³
Chain Locker: 215 m³
Foam / Detergent: 11.6 m³ / 11.6 m³
7. PUMPING & DISCHARGE SYSTEM
Fuel Oil Pump: 2 × 200 m³/h @ 90 m head
Potable Water Pump: 2 × 120 m³/h @ 90 m head
Drill Water Pump: 2 × 150 m³/h @ 80 m head
Liquid Mud Pump: 2 × 75 m³/h @ 80 m head
Dry Bulk Pump: 2 × 25.6 m³/h @ 5.6 bar
8. TOWING & ANCHOR HANDLING EQUIPMENT
AH / Towing Winch: 300 t pull, 450 t brake
Drum Capacity: 2,100 m × 76 mm
Anchor Windlass: 1 × 15 t (Brattvaag)
Anchor Chain: 2 × 330 m × 46 mm
Bow Anchors: 2 × 2020 kg HHP
Tugger Winches: 2 × 10 t
Capstans: 2 × 10 t
Deck Crane: 2.2 t at 12.2 m; 5.1 t at 3.0 m
Karm Forks: 2 × 300 t SWL
Tow Pins: 2 × 300 t SWL
Stern Roller: 5.0 m × 2.3 m, 450 t SWL
9. FIRE-FIGHTING SYSTEM (FIFI CLASS 1)
Fire Pumps: 2 × 1,600 m³/h @ 140 m head
Fire Monitors: 2 × (Water 1,200 m³/h / Foam 300 m³/h)
Oil Dispersant System: 2 × 6 m spray boom
10. NAVIGATION & COMMUNICATION
GMDSS Area 3 fully equipped
Radar: 2 × Furuno
Gyrocompass: 3 × Sperry
Magnetic Compass, Auto Pilot, DGPS, Echo Sounder, Speed Log, Anemometer, AIS, Navtex, EPIRB, SART, Inmarsat all installed
11. LIFE-SAVING EQUIPMENT
Life Rafts: 6 × 25 persons
Rescue Boat: 1 × 6 persons with davit
Lifejackets, Lifebuoys, Fire Extinguishers fully complied
12. ACCOMMODATION
Total Berths: 52 persons
10 × Single cabins
8 × Double cabins
2 × 3-man cabins
5 × 4-man cabins
