2016 Self-Propelled 400T Full Revolving Floating Crane

VESSEL INFO

• Offer type Ship for sale

• Type Crane Barge

• Classification China Classification Society

• Year of construction 2016

• Length 63.15m

• Width 26.3m

• Depth 4.9m

• Capacity 400 ML

• Asking price $ 9 700 000


DESCRIPTION

2016 Self-Propelled 400T Full Revolving Floating Crane

Year of Build: 2016
Place of Build: Guangdong
Navigation Area: Coastal A1
Gross Tonnage/Net Tonnage: 2255/687
Classification Society: Domestic CCS
Crew: 8 persons (not exceeding 8 hours)
Dimensions: Length Overall/Breadth/Depth: 63.15m / 26.30m / 4.90m
Full Load Draft: 2.70m
Full Load Displacement: 3950 tons
Light Ship Displacement: 2150 tons
Main Engine: 2 x Chongqing Cummins KT38 / 600KW
Generators: 2 x 350KW, 2 x 75KW

1. Main Hoist (360° Slewing) Parameters
Angle: 80 degrees
Longitudinal Radius (from ship): 3.5m
Transverse Radius (from ship): 2.1m
Lifting Height (hook): 48m
Lifting Capacity: 310 tons
2. Main Hoist (Fixed Longitudinal) Parameters
Angle: 80 degrees
Longitudinal Radius (from ship): 3.5m
Lifting Height (hook): 48m
Lifting Capacity: 400 tons
3. Auxiliary Hoist (360° Slewing) Parameters
Angle: 75 degrees
Longitudinal Radius (from ship): 13m
Transverse Radius (from ship): 11.7m
Lifting Height (hook): 68m
Lifting Capacity: 88 tons

The EX Chinese port price is usd9.7 million
