12M WORKBOAT / DAUGHTER CRAFT + LARS DAVIT / 12m Workboat / #1095679

VESSEL INFO

• Offer type Ship for sale

• Type Work Vessel

• Year of construction 2016

• Width 4.5m

• Deadweight 4 metric tons

• Asking price $ 1 500 000


DESCRIPTION

GRS identification number: #1095679

Availability: 2 months from order / SE ASIA
Class: BV / I ? HULL, ? MACH, Lightship – Fast Utility Vessel Sea Area 2
Length overall: 12.2 metres
Length hull: 12.2 metres
Beam (Moulded): 4.5 metres
12M WORKBOAT/DAUGHTER CRAFT
Draft loaded: 0.7 meters
Lightship: Approx. 12 tons
Fuel Oil: 1,800 litres
Passengers: 10
Engines: 2 x Cummins QSB-6.7 312kW (419bhp)
Propulsion: 2 x NAMJET TJ431HH Water Jets
Speed: Approx. 22 knots
Bollard Pull: Approx. 3.5 tons
Performance
The vessel shall be capable of achieving the following performance in calm water (up to sea state 2):
Speed 22 knots @ 100% MCR - based on 2.5 Dead Weight
Tonnes (DWT)
Bollard Pull 3.5 tons
DESIGN OPERATING CONDITIONS
Engineering systems shall be designed to operate under the following environmental conditions:
External air 0oC to + 40oC (80% relative humidity)
Machinery space Max 45oC
Sea water 0oC to 32oC
CLASSIFICATION & SURVEY
The vessel is constructed in accordance with the Bureau Veritas Classification Society Rules and
Regulations of Fast Utility Vessel. Plan approval and survey will be completed by Bureau Veritas to the
following notation: I X HULL l MACH Lightship - Fast Utility Vessel Sea Area 2
LARS DAVIT (available with or without the vessel)
Availability: Prompt, ex works EU CONTINENT
Make: Vest Davit
Davit model : PLD-15000
Power: 415V, 50Hz, 3ph, 142kW
SWL: 15,000kg
LOA 12.2 m
Beam 4.5 m
Built in year 2016
Flag : [Unknown]
Gross Tonnage of 14
Deadweight : 4 metric tonnes
Engines : 2 x Cummins / Cummins Engine Co Inc QSB6.7, 820 kw, 3,300 rpm, Propellers 1 Water Jet (Port Side) + 1 Water Jet (Starboard)
