79m / 500 pax Passenger / RoRo Ship / #1104410

VESSEL INFO

• Offer type Ship for sale

• Type Ro-Ro/Passenger Ship

• Year of construction 2018

• Length 78.6m

• Width 16.5m

• Asking price in broker currency € 6 011 309

• Asking price in your currency $ 6 925 639


DESCRIPTION

GRS identification number: #1104410

MAIN DIMENSIONS.
L.o.a. 74.500 m
B. ml.d 16.500 m
Depth 3,200 m
Design draught 2,200 m
Frame spacing 600mm
Free (net) main deck height: 5.180 m
DEADWEIGHT
Lightship is expected to be about 700 tn
Full displacement is expected to be about 1400 t at 2.20m draft.
Capacities Private Cars on main deck: 90 cars (4,50 x 1,80 m) and (OR) Trucks on main deck: 16 pieces (12m long each)
Classification Built under the survey of I.N.S.B. // Service in Port Areas
Tonnage 1000 GRT (Greek Regulation)
Speed Service Speed 12 knots.

HULL
The vessel is built of normal shipbuilding steel in the lower hull part, accommodation decks, and superstructure.
Deck loads main deck, area for trailers.
Road trailers: Axle load on the main deck: 16,5 tonnes
Painting and Cathodic Protection Protection of the underwater hull with zinc anodes.

MACHINERY MAIN COMPONENTS
General The vessel is equipped with four propulsion systems.
Main engines Four marine engines C18 CATERPILLAR with output 600 HP at 1800 RPM each.
Aux. engines Three aux. Engines CUMMINS, or CATERPILLAR
Electric power each: 110 KVA One port/emergency generator located above the main deck
Propeller plant Four rudder propeller systems VETH - TYPE VZ-400
Equipment Installed: - CO2 fire fighting system for engine rooms
Sprinkler fighting system for accommodation.
LOA 78.6 m
Beam 16.5 m
Draft 2.3 m
Total passenger capacity 500
1 Deck
abt. 90 Cars
Built in year 2018
Class : International Naval Surveys
Flag : Greece
Gross Tonnage of 1,500 and Nett Tonnage of 750
Speed : 14 knots
Engines : 4 x Caterpillar / Caterpillar Inc C18, 1,800 kw, Propellers 4 Z Type (Other Position)
