DP2 Multi-Purpose Support Ship

VESSEL INFO

• Offer type Ship for sale

• Type Multi-Purpose Vessel

• Year of construction 1976

• Length 91m

• Width 18m




• Asking price $ 2 850 000


DESCRIPTION

COMMENTS This is a 298’ Multi-Purpose DP II Dive and Construction Support OSV built in 1976 and converted in 1985. Major overhauls and upgrades were done in 1992 and 2005. It is RINA Class for unrestricted navigation. Special features include a 50 ton heave compensated crane, multiple deck cranes, moon pool, FiFi capability, DP2, and berths and accommodation blocks for up to 87 personnel. Most recent operations have been in construction support and multi-purpose support roles. The ship is well priced for sale and is also available for charter. GENERAL INFORMATION Type: DP 2 Multi-Purpose OSV/Construction Support Builder: Smedvik Mek Verkshed, Norway Year Built: 1976, major upgrades 1985/1992/2005 Class: RINA Class Notation: RINA * Supply Vessel, Unrestricted Navigation DYNAPOS A/M/AT R, SPS Survey Area: Unrestricted DIMENSIONS LOA: 90.52 m/297 ft Beam: 18 m/59 ft 1 in Max Draft: 4.5 m/14 ft 8 in Working Draft: 3.5 m/11 ft 6 in Air Draft: 21.5 m/70 ft 5 in Deadweight: 2,000 mt Gross Tonnage: 3,186 mt Net Tonnage: 755 mt SPECIAL FEATURES Deck Crane: 50 Ton Articulating/Heave Compensated Moon Pool: 3.25 m x 3.2 m Dynamic Position: Alstom Dual Redundancy DP II Accommodation: 82 berths Clear Deck Space: 1,000 m2 Deck Cargo: 1,500 mt Deck Strength: 5 mt/m2 FiFi System: 1 x 100 m3/minute pump 1 x 200 m3/minute pump MACHINERY Main Engines: 2 x MAK 453 AK @ 2,000 HP Total Power: 4,000 HP Generators: 2 x 269 KW 1 x 1,200 KW 1 x 1,750 KW 1 x 153 KW 2 x 808 KW All generators @ 440v/240v Bow Thruster: 2 x Ulstein 90 TV, 500 BHP Stern Thruster: 2 x Ulstein VROS 230, 1,000 BHP Propulsion: 2 x Controllable Pitch Propellers PERFORMANCE Max Speed: 12 kts Service Speed: 10 kts Consumption: @ 12 kts 12 mt/24 hr @ 10 kts 10 mt/24 hr @ DP mode 9 mt/24 hr @ in Port 1.0 mt/24 hr Tank Capacity: Gas Oil: 1,300 m3 Fresh Water: 1,000 m3 Ballast Water: 2,347 mt Lube Oil: 10.8 m3 Sewage Water: 139 mt Sludge: 3.3 mt Dirty Water: 4.0 mt NAVIGATION/COM MUNICATION Radar: 1 x Koden KW2 1 x Furuno TSR 4241 Gyro Compass: 1 x SR220,10113 Sperry 1 x GL 80/85 SIMRAD Inmarsat C: 1 x Sailor 6110 GMDSS 1 x Sailor 250 (TT 3742A) VHF Station: 2 x RT 5022 RF-HF Radio: 2 x Sailor Compact 2000 AIS: 1 x JHS-182 Echo Sounder: 1 x Furuno FE 700 GPS: 1 x NW2-4570 Navtex Receiver: 1 x NCR-333 SAFETY EQUIPMENT Portable GMDSS: 3 x Tron TR 30 GMDSS Life Rafts: 16 x 25 Person Rescue Craft: 1 x 4.25 m 6 Person SART: 2 x Tron SART 20 EPIRB: 1 x SE406 II Life Buoys: 2 x Light & Smoke 7 x Self Igniting Light Buoy 3 x Life Buoys/Line DECK EQUIPMENT Windlass: 1 x 10 ton Anchors: 2 x Brunson 2500/2,568 kg Deck Cranes: 1 x 50 ton Heave Compensated 1 x 1.5 ton 1 x .5 ton 1 x 2.2 ton ACOMMODATIONS 2 Berth Cabins: 25 1 Berth Cabins: 3 Hospital: 1 Additional: 4 x 8 man block accommodations Most recent operations have been in construction support and multi-purpose support roles. The ship is well priced for sale and is also available for charter.
