119m / DP 3 Offshore Support & Construction Vessel / #1062347

VESSEL INFO

• Offer type Ship for sale

• Type Support Vessel

• Year of construction 2003

• Length 119.3m

• Width 27m



• Deadweight 8018 metric tons

• Capacity 250 ML



• Asking price Price on request


DESCRIPTION

GRS identification number: #1062347

LOA 119.3 m
Beam 27 m
Draft 8.8 m
Built in year 2003
Design is : VS 4201 OCV
Class : DNV
Flag : Norway (NIS)
Gross Tonnage of 12,913 and Nett Tonnage of 3,874
Dynamic Positioning of class : DP 3
Free Deck area about 1,516m² with a deck strength of 15 metric tonnes per square meter
Heli Deck installed
Moon pool 7.2m x 7.2m installed
1 Crane / Gear installed with a max lifting capacity of 250 tons
1 Crane / Gear installed with a max lifting capacity of 30 tons
Deadweight : 8,018 metric tonnes
Bollard Pull : 229 tons
Ice classed 1C
Capable of supplies of 3,400m³ Fuel Oils and 1,400m³ FW
Total passenger capacity 135 with 126 berths
54 cabins with 1 berth
36 cabins with 2 berths
Speed : 14.5 knots
Engines : 2 x Caterpillar / Caterpillar Inc 3616TA, 12,000 kw, 1,000 rpm, Propellers 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
Auxiliaries Engines : 2 Caterpillar 2,300 kw + 2 Caterpillar 1,900 kw, Bowthruster + Sternthruster (2 Bow Tunnel thruster 1,425kw + 1 Bow Retract. dir. thruster 1,200kw + 2 Stern Tunnel thruster 1,425kw)
