99m / DP 2 Offshore Support & Construction Vessel

VESSEL INFO

• Offer type Ship for charter

• Type Support Vessel

• Year of construction 2011

• Length 98.6m

• Width 19m



• Deadweight 3800 metric tons

• Capacity 150 ML



• PRICE Price on request


DESCRIPTION

GRS identification number: #1071480

LOA 98,6 m
Beam 19 m
Draft 6,6 m
Built in year 2011
Design is : Ulstein SX130
Class : DNV
Flag : Marshall Islands
Gross Tonnage of 6.072 and Nett Tonnage of 1.822
Dynamic Positioning of class : DP 2
Free Deck area about 844m² with a deck strength of 10 metric tonnes per square meter
Heli Deck installed
Moon pool 7,2m x 7,2m installed
1 Crane / Gear installed with a max lifting capacity of 3 tons
1 KNB installed with a max lifting capacity of 150 tons
1 KNB installed with a max lifting capacity of 6 tons
Deadweight : 3.800 metric tonnes
Bollard Pull : 60 tons
Ice classed 1C
Capable of supplies of 1.650m³ Fuel Oils and 1.000m³ FW
Total passenger capacity 75 with 75 berths
7 cabins with 1 berth
8 cabins with 1 berth
14 cabins with 2 berths
2 cabins with 1 berth
9 cabins with 2 berths
2 cabins with 6 berths
Speed : 10,5 knots
Engines : 5 x Caterpillar / Caterpillar Inc 3516B, 9.505 kw, 1.800 rpm, Propellers 1 Azimuth Elec. Dr. (Port Side) + 1 Azimuth Elec. Dr. (Starboard)
Auxiliaries Engines : Bowthruster + No Sternthruster (2 Bow Tunnel thruster 2.500kw + 1 Bow Retract. dir. thruster 850kw + 2 Bow Tunnel thruster 1.200kw)
