78m / DP 2 Offshore Support & Construction Vessel

VESSEL INFO

• Offer type Ship for charter

• Type Support Vessel

• Year of construction 2006

• Length 78.3m

• Width 17.2m



• Deadweight 3024 metric tons

• Capacity 5 ML



• PRICE Price on request


DESCRIPTION

GRS identification number: #1065096

LOA 78,3 m
Beam 17,2 m
Draft 7 m
Built in year 2006
Design is : UT 712-L
Class : China Classification Society
Flag : Gabon
Gross Tonnage of 3.068 and Nett Tonnage of 1.057
Dynamic Positioning of class : DP 2
Free Deck area about 510m² with a deck strength of 10 metric tonnes per square meter
Fire Fighting System installed
1 Crane / Gear installed with a max lifting capacity of 5 tons
2 Cranes / Gears installed with a max lifting capacity of 3 tons
Deadweight : 3.024 metric tonnes
Bollard Pull : 180 tons
Capable of supplies of 1.060m³ Fuel Oils, 741m³ FW, 538m³ Liquid Mud and 952m³ Brine
Total 28 berths
12 cabins with 1 berth
4 cabins with 2 berths
2 cabins with 4 berths
Speed : 12 knots
Engines : 4 x Bergens / Rolls-Royce Marine AS C25:33L9P, 10.800 kw, 1.000 rpm, Propellers 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
Auxiliaries Engines : 1 Caterpillar 910 kw, Bowthruster + Sternthruster (1 Bow Thwart. CP thruster 883kw + 1 Bow Retract. dir. thruster 883kw + 1 Stern Thwart. CP thruster 883kw)
