94m / DP 2 Offshore Support & Construction Vessel

VESSEL INFO

• Offer type Ship for charter

• Type Support Vessel

• Year of construction 2009

• Length 93.6m

• Width 19.7m



• Deadweight 4247 metric tons

• Capacity 100 ML



• PRICE Price on request


DESCRIPTION

GRS identification number: #1068292

LOA 93,6 m
Beam 19,7 m
Draft 6,29 m
Built in year 2009
Design is : MT-6016
Class : DNV
Flag : Brazil
Gross Tonnage of 4.869 and Nett Tonnage of 1.588
Dynamic Positioning of class : DP 2
Free Deck area about 947m² with a deck strength of 10 metric tonnes per square meter
Heli Deck installed
Moon pool 6m x 5,3m installed
Saturated Diving System installed
2 Cranes / Gears installed with a max lifting capacity of 5 tons
1 KNB installed with a max lifting capacity of 100 tons
Deadweight : 4.247 metric tonnes
Ice classed 1C
Capable of supplies of 1.150m³ Fuel Oils and 1.000m³ FW
Total passenger capacity 68 with 68 berths
16 cabins with 1 berth
26 cabins with 2 berths
Speed : 14 knots
Engines : 4 x Caterpillar / Caterpillar Inc 3516, 9.698 kw, 2.100 rpm, Propellers 1 Azimuth Elec. Dr. (Port Side) + 1 Azimuth Elec. Dr. (Starboard)
Auxiliaries Engines : 2 Caterpillar 550 kw, Bowthruster + No Sternthruster (1 Bow Retract. dir. thruster 883kw + 2 Bow Tunnel thruster 883kw)
