94m / DP 2 Offshore Support & Construction Vessel

VESSEL INFO

• Offer type Ship for charter

• Type Support Vessel

• Year of construction 2009

• Length 93.6m

• Width 19.7m



• Deadweight 4500 metric tons

• Capacity 100 ML



• PRICE Price on request


DESCRIPTION

GRS identification number: #1068365

LOA 93,6 m
Beam 19,7 m
Draft 6,3 m
Built in year 2009
Design is : MT 6017
Class : DNV
Flag : Bahamas
Gross Tonnage of 4.850 and Nett Tonnage of 1.450
Dynamic Positioning of class : DP 2
Free Deck area about 1.046m² with a deck strength of 10 metric tonnes per square meter
Heli Deck installed
Moon pool 6m x 5,3m installed
1 KNB installed with a max lifting capacity of 100 tons
2 KNB installed with a max lifting capacity of 5 tons
Deadweight : 4.500 metric tonnes
Ice classed 1C
Capable of supplies of 1.150m³ Fuel Oils, 175m³ Methanol, 1.000m³ FW, 860m³ Liquid Mud and 495m³ Brine
Total passenger capacity 68 with 68 berths
18 cabins with 1 berth
25 cabins with 2 berths
Speed : 12 knots
Propulsion is Diesel Electric
Engines : 4 x Caterpillar / Caterpillar Inc 3516D, 8.752 kw, 1.800 rpm, Propellers 1 Azimuth Elec. Dr. (Starboard) + 1 Azimuth Elec. Dr. (Port Side)
Auxiliaries Engines : Bowthruster + No Sternthruster (2 Bow Tunnel thruster 883kw + 1 Bow Retract. dir. thruster 883kw)
