VESSEL INFO

  • Offer type Ship for sale
  • Type Anchor Handling Tug Supply Vessel (AHTS)
  • Classification China Classification Society
  • Year of construction 2009
  • Length 67m
  • Width 16m
  • Depth 7m

  • Capacity 2 ML

  • Asking price $ 13 300 000

DESCRIPTION

2009 built 10800BHP AHTS Vessel
Integrating functions such as offshore towing, supply, firefighting, standby rescue, and salvage operations.

Class Notation (CSA): Includes AUTO and DP2 (Dynamic Positioning Level 2) certifications.

Built: 2009
Class: CCS
Length Overall (LOA): 67m
Beam: 16m
Depth: 7m
Maximum Draft: 6m
Displacement at Full Draft: 2,000 tons

Main Engines:
2 × Wärtsilä 8L32 (Total power: 10,872 BHP)
Propulsion: Controllable Pitch Propeller (CPP)
Maximum Speed:13.5 knots (Average fuel consumption: 30 tons/day)
Economical Speed: 12 knots (Average fuel consumption: 20 tons/day)
Bollard Pull: 142 tons (Capable of heavy-duty towing and anchor handling)

Deck Specifications:
- Area: 420 m²
- Strength: 5 tons/m²
- Dimensions: 35m × 12m
- Cargo Capacity: 800 tons

Tank Capacities:
- Ballast Water: 437 m³
- Fresh Water: 239 m³
- Fuel Oil: 1,194 m³
- Mud: 399 m³
- Sea Water: 399 m³
- Freezer/Chiller Room: 8 m³

Deck Equipment:
- Mooring Winches: 2 × 10T (Speed: 14.6 m/min)
- Towing Winches: 2 × 11T (Speed: 18.9 m/min)
- Crane: 2T × 15m
- Rescue Boat: 10-person Sea Bear 23 MKII with MacGregor 3.2T davit
- Anchor Windlass: 12T (Speed: 14.5 m/min)

Utility Systems:
- Dewatering Pumps: 2 × 50 m³/h (for bulk discharge)
- Firefighting Monitors: 2 × 1,200 m³/h (dual-purpose for firefighting and washdown)

Propulsion & Maneuvering:
- Bow Thrusters: 2 × 8T (electric-driven)
- Stern Thruster:1 × 8T (electric-driven)
- DP2 System: Equipped with 2 sets of GPS + CyScan for high-precision positioning and operational stability.

Power Plant:
- Shaft Generators: 2 × 1,520 kW
- Auxiliary Generators:2 × 590 kW (diesel)
- Emergency Generator:84 kW
- Voltage: 440V / 220V

Accommodation:
Single cabins, double cabins, 4-person cabins, and a mess room to meet crew living requirements.

The EX Chinese port price is usd13.3 million
