Delivery in 2026 6800HP AHTS with DP2

VESSEL INFO

• Offer type Ship for sale

• Type Anchor Handling Tug Supply Vessel (AHTS)

• Classification China Classification Society

• Year of construction 2025

• Length 59.20m

• Width 14.95m

• Depth 6.1m



• Deadweight 1742 metric tons

• Capacity 2 ML



• Asking price $ 9 770 000


DESCRIPTION

Delivery in 2026 6800HP AHTS with DP2

Year of Build：2010-9-26
Completion time: 2026
Flag: China
Classification Society：CCS
Length Overall：59.20
Molded Breadth：14.95m
Molded Depth：6.10m
Loaded Draft：5.0m
Light Draft：2.78m
Gross Tonnage：1734 tons
Net Tonnage：971 tons
Deadweight：1742 tons

Deck Area：330㎡
Deck Cargo Capacity：850T
Deck Strength：5.5T/㎡
Cargo Hold Capacity
Bulk Cargo Tank：177 m³
Drinking Water Tank：447.2 m³
Fuel Oil Tank：575.2 m³
Mud Tank：248.1 m³

Transfer Rate
Ash Transfer：132 m³/h
Water Supply：100 m³/h
Drilling Water Transfer：100 m³/h
Fuel Supply：100 m³/h
Mud Transfer：75 m³/h

Machinery
Main Engine：G8320ZC28/3B
Main Engine Power：2500KW×2
Propeller：Controllable Pitch Propeller
Generator Sets：Shaft Generator 800KW×2,
400KW×2+120KW Emergency Generator
Bow Thruster：1 unit, CTT1300-CP, 450KW, Diameter 1300
Stern Thruster：1 unit, CTT1100-CP, 280KW, Diameter 1100
Bollard Pull：766.7KN（78T）
Deck Crane：2T×12m

Speed
Maximum Speed：13.2 knots
Economic Speed：11 knots

Towing/Anchor Handling Equipment
Towing Winch：125T×8m/min
Towing Drum：φ900×2150
Towing Rope：φ60×1200m
Anchor Handling Drum：φ900×2150
Anchor Handling Rope：φ60×1000m
Stern Drum：φ1800×3540MM
Shark Jaw：300T
Release Pin：With emergency release function

Safety/Fire Fighting/Anti-Pollution Equipment
Life Raft：2 units, 25 persons each
Workboat：1 unit, 6-person rescue boat
External Fire Fighting：The vessel adopts foam fire-extinguishing system for auxiliary external fire fighting, equipped with 1 fire monitor + fire pump (Model: OTS250-450A, Capacity: 450m³/h, Head: 130m, Speed: 1800rpm) to cover its own fire protection and that of other vessels）
Anti-Pollution Equipment：1 set of new standard oily water separator, 1.0 m³/h, Model: ZYFM-1-107-49

Navigation/Communication Equipment
MF/HF Radio：SRG-3150（1 set）
ECDIS：XINUO211
Radar (Furuno)）：FR2117（21-inch）
Radar (Furuno)）：FR8062
Radar Transponder：SAR-9（2 sets）
AIS：AWS-1
GPS：GP-1400
Echo Sounder：DSO-2008
EPIRB：SEP-406
NAVTEX Receiver：NX-300
Reflecting Magnetic Compass：CGT165
Gyro Compass：CLP-2B
VHF Radio：2 units of VHF Radio (SRG-6000A), 3 units of Two-way Radio (STV-160)）
Fitted with DP2

Personnel Configuration
Crew：13
Passengers：18

The EX Chinese port price is usd9.77 million
