出售乘客人数 200 人 /车辆45部客滚船。

VESSEL INFO

• Offer type Ship for sale

• Type Passenger Landing Craft

• Classification China Classification Society

• Year of construction 1998

• Depth 00m




• Asking price Price on request


DESCRIPTION

出售乘客人数 200 人 /车辆45部客滚船。
Flag:China.
Class:CCS.
一、船舶基本参数
船舶类型: 车客渡船 /船舶类型说明/ III级客船.
最大船员人数 8 人/ 乘客人数 200 人 /车辆45部。
安放龙骨日期/建造完工日期1998-04-01/1998-06-22改建开工/完工日期
船舶建造：中国船舶修造厂。
二、船体部分
总长 53.60m/船长 48.00 1m /满载水线长 48.00m
/船宽 17.40 17m
/ 型深 5.20 11m
/空载吃水 2.045 m/
满载吃水 2.700 m.
满载排水量 899.100 t /空船排水量 618.700 t。
船体材料 钢质 /水密横舱壁数 00.
结构型式纵横混合骨架式 /货舱的数量 0.
双层底位置 /进水角位置 /主甲板门槛/ 抗沉性 /满足2004法规.
GRT1224/NRT636.
三、锚设备
名称 型式 重量(kg) 数量:
石艏键 霍尔锚 900.00
左艏键 霍尔锚 900.00
左艏锚1 大抓力锚 1080.00
名称 型号 功率(kW) 数量
锚机 右艏锚机 立式电动
0
左艏锚机 立式电动 6
左艏锚机 DMJE-28-2-45 1 1
名称 直径(mm) 长度(m) 等级 材料
右艏锚链 28.00 175.00 AM2级 M20Mn 锚链
左艏锚链 34.00 175.00 AM2级 M20Mn
左艏锚链1 28.00 175.00 AM2 2级链钢
四、舵设备
舵数量 ( 主操舵装置型式 电动液压/
应急能源种类 辅助操舵装置型式.
五.推进装置：
主机 300.00KW /1000RPM@2台/
2008年12月05H 山东巨力股份有限公司/
型号X6170ZC-O5.
齿轮箱型号 HCD400A HCD400A。
1#螺旋桨轴 1中间轴 2#螺旋桨轴 2中间轴：
名称160/ 140/ 160 /140.
营运区域：A1（沿海）。
We are selling 45 ro-ro passenger ships with a capacity of 200 passengers per vehicle.
Flag:China.
Class:CCS.
I. Basic Parameters of Ships
Vessel type: Passenger ferry/Vessel type description/Class III passenger ship.
The maximum number of crew members is 8, the number of passengers is 200, and there are 45 vehicles.
Date of laying the keel/Completion date of construction: April 1, 1998 / June 22, 1998 / Start date of renovation/Completion date
Shipbuilding: China Shipbuilding Repair and Construction Corporation.
Ii. Hull section
Total length: 53.60 meters/Length: 48.00 meters/Full-load waterline length: 48.00 meters
The ship is 17.40 17 meters wide
/ Type depth: 5.2011 meters
The no-load draft is 2.045 m/
The full-load draft is 2.700 meters.
The full-load displacement is 899.100 tons and the empty displacement is 618.700 tons.
Hull material: Steel/watertight transverse bulkhead number: 00.
Structural type: longitudinal and transverse hybrid frame type/Number of cargo holds: 0.
Double-layer bottom position/water inlet Angle position/main deck sill/anti-sinking property/complies with 2004 regulations.
GRT1224/NRT636.
Iii. Anchor Equipment
Name Type Weight (kg) Quantity:
Stone bow key Hall anchor 900.00
Left bow key Hall anchor 900.00
Left bow anchor 1 high grip anchor 1080.00
Name Model Power (kW) Quantity
The right bow anchor crane is vertical electric
0
Left bow anchor machine vertical electric 6
Left bow anchor crane DMJE-28-2-4511
Name Diameter (mm) Length (m) Grade Material
Right bow anchor chain 28.00-175.00 AM grade 2 M20Mn anchor chain
Left bow anchor chain 34.00-175.00 AM grade 2 M20Mn
Left bow anchor chain 1 28.00 175.00 AM2 grade chain steel
Iv. Rudder Equipment
Number of rudders (main steering device type: electric hydraulic /
Types of emergency energy and auxiliary steering device types.
V. Propulsion Device:
Main unit: 300.00KW /1000RPM@2 units /
December 5, 2008 Shandong Juli Co., LTD
Model X6170ZC-O5
Gearbox model: HCD400A.
1# Propeller Shaft 1 Intermediate shaft 2# propeller Shaft 2 intermediate shaft
Name: 160/140/160/140.
Operating area: A1 (Coastal).
