2024-built 5150HP AHTS with DP1

VESSEL INFO

• Offer type Ship for sale

• Type Anchor Handling Tug Supply Vessel (AHTS)

• Classification American Bureau of Shipping

• Year of construction 2024

• Length 59.25m

• Width 14.95m

• Depth 6.1m

• Asking price $ 15 900 000


DESCRIPTION

2024-built 5150HP AHTS with DP1

GENERAL

Year Built: 2024

Builder: FUJIAN SHIPBUILDING

Classification: ABS+A1(E) + AMS Towing + DPS-1+Offshore Support Vessel

Dimension L×B×D: 59.25m × 14.95m × 6.10m

Draft: 4.95m Loaded; 5.90m

GRT/NRT: 1678/503

DWT: 1300mt approx

CARGO CAPACITY

Fuel Oil: 527.6 m³

Potable Water: 301.71 m³

Drill Water: 401.96 m³

Liquid Mud/Brine: 378m³/166m³

Dry Bulk (4nos): 4×1650ft³

Deck Cargo: 500T

Deck Strength: 7.5mt/m²

Clear Deck Space: 320 m² approx

REFRIGERATED STORAGE

Cold Room: 15m³

ACCOMODATION (Fully Air-Conditioned)

4×1 berth cabin = 4

3×2 berth cabin = 6

8×4 berth cabin = 32

Total​ = 42

Hospital x1 - 1man = 1

NAVIGATION & COMMUNICATION

Doppler Speed Log: 1 x Furuno DS-80

X Band Radar: 2 x Furuno FAR-2117

Gyro Reperter: 3 x Raytheon Anschutz Gmbh STD 22

Navtex Receiver: 1 x Furuno NX-700A

EPIRB: 1 x OCEAN SIGNAL E100

Autopilot: 1 x Raytheon Anschutz Gmbh NP60

GPS Plotter: 1 x Furuno GP-150

Echo Sounder: 1 x Furuno FE-700

Inmarsat-C: 2 Units FELCOM-18

AIS: 1 x Furuno FA-150

VHF: 1 x Furuno FM-8900S

Magnetic Compass: LILEY&GILLIE MK200


ANCHOR HANDLING EQUIPMENT

Winch: 1x electro-hydraulic AHTW MacGREGOR

Brake Holding: 200mt static at first layer

Drum Wire Cap:Tow-1000mm×56mm, AH1000m×56mm

Spare Winch: 1000m×56mm

Tugger Winch: 250m×22mm

Shark Jaw: 1 electro-hydraulic -SWL 200mt

Capstan: 2 x 5mt 15m/min ,hydraulic driven

Stern Roller: 1 unit 4000mm x 1600mm SWL 200 MT


MAIN MACHINERY & PROPULSION

Main Engine: 2 x CAT 3516C, 2575 (5150bhp) @1600rpm

Auxiliary Engine: 2 x CAT 350KW

Emergency Generator: 1XCAT 65KW

Propulsion: 2 x CPP with Nozzles

Shaft Generator: 2 x 800KW, 415/3/50

Bow Thruster: 2 X 8MT



ANCHOR & CRANES

Anchor: 2×AC-14 High hold type

Chain: Total length 440Mx36MM/GradeU2

Deck Crane: 1 x SWL 3.0mt @ 9m


CARGO PUMP CAPACITY

Fuel Oil: 1 x 150m³/h @ 75m head

Potable Water: 1 x 125m³/h @ 75m head

Drill Mud: 1x 100m³/h @ 75m head

Liquid Mud: 2 x 75m³/h @ 75m head

Brine pump: 1 x 75m³/h @ 75m head

Ballast: 1 x 75m³/h @ 55m head

Dry Bulk Compressor: 2X13m³/min

Reefer Power Point: 4 x 415V 220V

Sewage Treatment: WCMBR-50(U)

FIRE FIGHTING (FIFI1) & ANTI-POLLUTION


Pump: 2 x 1680m³/h @ 121m head driven by PTO of M/E

Monitor: 2 x 1200m³/h

Oil Dispersant Boom: 2 spray boom 6m (8 nozzles each)

Oil Dispersant Tank: 13.31 m³


BOLLARD PULL : 65T.

DP: DP1


SPEED

Maximum Speed (MCR100%): 14.03 Knots

Economical Speed (MCR75%): 13.45 Knots

ENDURANCE

15 days

The EX Chinese port price is usd15.9 million
